Ruijie RG-CS83-24GT4XS-P — Layer-3 Managed PoE+ Access Switch
Key Highlights / Features
24 × 10/100/1000 Mbps RJ45 ports (each supports PoE / PoE+ per 802.3af/at) Visiotech | Security Systems Supplier+2ruijie.com+2
4 × 1G / 10G SFP+ uplink ports for high-speed optical connectivity Sysnet Center+3ruijie.com+3telco.ge+3
Switching capacity: ~ 128 Gbps telco.ge+2Sysnet Center+2
Packet forwarding rate: ~ 96 Mpps telco.ge+2Visiotech | Security Systems Supplier+2
PoE budget: 370 W total telco.ge+2shopdelta.eu+2
Surge / lightning protection: up to 10 kV on interfaces, 6 kV / 8 kV on power / PoE lines Sysnet Center+2media.mayflex.com+2
Multi-protocol routing support: Static routing, RIP, OSPF (IPv4 & IPv6) Sysnet Center+2Sysnet Center+2
Virtual Switch / Virtual Stacking (VSU) support for redundancy & flexible topologies Sysnet Center+2Sysnet Center+2
High reliability features: BFD, RLDP, ERPS / REUP, VRRP, fast fault detection, link convergence telco.ge+3Sysnet Center+3ruijie.com+3
Security & access protection: ACL, 802.1x, IP source guard, CPP / NFPP, DHCP snooping, port isolation Visiotech | Security Systems Supplier+3Sysnet Center+3Sysnet Center+3
QoS / traffic management: 8 priority queues per port, traffic policing, DSCP / 802.1p, SP / WRR / DRR / WFQ etc. Sysnet Center+2Sysnet Center+2
VLAN and tunneling: 4,096 VLANs (802.1Q), QinQ, VLAN translation, Private VLANs, GVRP media.mayflex.com+3Sysnet Center+3ruijie.com+3
Management & monitoring: Web GUI, CLI, SNMP v1/v2/v3, RMON, Cloud / APP, GRPC, NETCONF etc. Sysnet Center+3Sysnet Center+3ruijie.com+3
Open & programmable OS (RGOS modular) — ability to extend via “apps” or Python scripting Sysnet Center+2ruijie.com+2
Compact design: Depth ~ 220 mm, 1U rack form factor Sysnet Center+2media.mayflex.com+2
Operating environment: 0 °C to 45 °C, humidity / non-condensing conditions Sysnet Center+1
Hardware & Physical Specifications
| Parameter | Value |
| Dimensions (W × D × H) | 442 × 220 × 43.6 mm media.mayflex.com+2Sysnet Center+2 |
| Weight (unit) | ≈ 3.0 kg (approx) Visiotech | Security Systems Supplier+2telco.ge+2 |
| Power Input | AC 100 V – 240 V, 50/60 Hz telco.ge+1 |
| Fan / Cooling | Fixed fan module (with intelligent speed control) Sysnet Center+2media.mayflex.com+2 |
| Memory / CPU / Storage | Dual-core CPU; 1 GB RAM; Flash / Boot ROM (various) ruijie.com+2Sysnet Center+2 |
| MAC / ARP Table Sizes | MAC ~ 16K (or up to 16,000 entries) telco.ge+2Sysnet Center+2 ARP ~ 4,000 entries Sysnet Center+1 |
| Switching Capacity | 128 Gbps telco.ge+2Sysnet Center+2 |
| Packet Forwarding Rate | 96 Mpps telco.ge+2ruijie.com+2 |
| PoE Budget | 370 W (total across ports) telco.ge+2shopdelta.eu+2 |
| Surge Protection (data ports) | 10 kV ruijie.com+3Sysnet Center+3media.mayflex.com+3 |
| Surge / Power Protection | 6 kV / 8 kV (PoE / power lines) Sysnet Center+2media.mayflex.com+2 |
Use Cases & Applications
Enterprise campus / building network access layer
PoE-powered devices: IP cameras, wireless access points, VoIP phones
Networks requiring multiple uplinks and high-speed aggregation (via SFP+ ports)
Environments with high reliability / redundancy / fast failover requirements
Scenarios demanding advanced routing, segmentation, QoS, and security
